Instruction Manual

1

Introduction

Packaging Contents

ID Name Qty

Rack Components

1 Left Vertical Rail 2

2 Right Vertical Rail 2

3 Base Bracket 2

4 Corner Section 8

5 Center Section 4

6 Top Bracket 2

Rack Assembly Hardware

10 M8 Bolt 48

11 M8 Washer 48

Rack Assembly Tool

12 M8 (13 mm) Wrench 1

13 M6 (10 mm) Wrench 1

14 Phillips Screwdriver 1

Equipment Mounting Hardware

15 M6 Cage Nut 24

16 PVC Cup Washer 24

17 M6 Philips-Head Screw 24

Cable Management Hardware

18 Cable Management Hook 4

19 Hook Mounting Screw 4

Casters and Hardware

20 Casters 4

21 Levelling Feet 4

22 M6 Screw 16

23 M6 Flat Washer 16

24 M6 Flange Nut 16

25 Grounding Wires 4

10 11 12

15 16 17

13 14

18 19

20

21

22

23 24

20

21

25
